Electronics testing
Electronic components are now integrated into any device and are subject to multiple uses in critical conditions, exposed to thermal, mechanical and chemical stresses. It is essential to have technical certainty that these materials will be safe and durable in accordance with how they were designed and manufactured.
Testing for the electronics industry in TEC Eurolab
TEC Eurolab supports companies in the electronics industry in verifying the correspondence between the expected performance of the component and its actual application in operation.
Our laboratories provide testing services to support the entire production chain of: electronic boards, pins, wiring harnesses, electric motors, solenoid valves and sensors. Components specific to this sector require third-party verification to confirm material characteristics in strict compliance with technical supply specifications.
Analysis activities are inserted to support all phases of the product life cycle. From the concept developed in the research and development departments to the industrialization phase and subsequent putting into production, we structure together with the customer a test plan for the validation of the entire production process.
Applying specific investigation methodologies, the laboratory verifies structural and environmental characteristics such as:
- mechanical strength
- fatigue strength
- chemical resistance
- resistance to thermal shock or surges
- temperature cycling
- atmospheric aging
The laboratory also supports companies in obtaining RoHS certification and performs specific analysis according to IPC-TM-650.
Functional tests
- Tests of conductivity, electrical resistivity and insulation
- Temperature- and humidity-controlled climate chamber tests
- IP testing for water and dust tightness
- Evidence of Thermal Shock
Learn about the quality control service of electronic assemblies according to the IPC-A-610 standard
Dimensional checks
- Dimensional checks by CMM
- Optical machine
- Laser arm
Non-destructive testing
- Visual inspection of components in accordance with international standards
- 2D radiographic inspection of electronic components
- Industrial computed tomography with micrograph MICRO CT
- Visual examination of brazed joints
Metallurgical analysis
- Macrographic and micrographic examinations of sections
- Study and observation of surfaces using SEM (scanning electron microscope)
- Analysis of welds
Chemical and physical analysis
- Characterization of surfaces and coatings
- Chemical analysis of metallic and polymeric components
- Accelerated aging tests (salt spray, UV, climatic chambers)
- Contamination testing
- Failure Analysis
Mechanical testing
- Material characterization (pull off, shear, tensile, vibration)
Main electronics industry standards to which we respond
RTCA DO-160G
Environmental, EMC, vibration, and leakage testing on avionics (civil and military aircraft, avionics and LRU equipment, on-board electronic systems, equipment intended for fixed-wing, rotary-wing, and UAV aircraft).
RTCA DO-254
MIL-STD
- MIL-STD-810G: vibration, shock, temperature, humidity
- MIL-STD-461G: Electromagnetic Compatibility
- MIL-STD-202H: resistance, vibration, humidity and functionality on electrical components
IPC-A-610
Quality inspections on electronic assemblies (PCBA)
IEC 60068-2
Environmental simulation: hot, cold, vibration, shock
IEC 60529
IP rating: protection against dust and water ingress
IEC 62262
Degree of protection IK: resistance to mechanical impact
IPC-TM-650
- IPC-TM-650-2.3.25: Detection and measurement of ionizable surface contaminants by ion chromatography
- IPC-TM-650-2.3.28: Ionic analysis of printed circuit boards, ion chromatography method
- IPC-TM-650-2.6.7.2: Thermal shock, thermal cycling and verification of electrical continuity.
- IPC-TM-650-2.4.24: Glass transition and modulus of the materials used in High Density Interconnection (HDI) and microvias – DMA method
